- 5 /2 Watt RF Output Power
- 1,024Channel in 32 Groups
- Built in Compander
- Remote Stun / Revive
- TOT/BCL/BCLO
- Priority and Conventional Scanning
- Emergency Function
- Lone Worker
- 10Steps S.Q(Squelch) level select
- 5 Steps VOX level setting
- PC 를 이용한 방송 콘트롤
- MIL-STD-810 F and IP-54
- DC 7.4V 2,600 mAH Li-ion Battery
| General | |
|---|---|
| XR-100/150 VHF | 136 ~ 174 MHz |
| XR-400/450 UHF | 410 ~ 470 MHz |
| Channel Capacity | 1,024 |
| Channel Spacing | 12.5KHz |
| Frequency Stability | ±2.5ppm(-30℃∼+60℃) |
| Dimensions | 102mm(H) x 52mm(W) x 33mm(D) |
| Dust & Waterproof | IP54 |
| Battery | DC+7.4V 2,600mAH Li-ion |
| Weight | 250g |
| 환경 규격 | |
|---|---|
| 동작 온도 | -30℃∼+60℃ |
| 방진 방수 | IP67 |
| Receiver | |
|---|---|
| Sensitivity | 0.22uV 12dB SINAD |
| Squelch Sensitivity | 0.20uV 10dB SINAD |
| Adjacent Channel Selectivity | 60dB |
| Intermodulation | 60dB |
| Spurious Rejection | 70dB |
| S/N Ratio | 40dB |
| Audio Response | +1 /- 3dB from 6dB per octave de-emphasis characteristic |
| Audio output | 1 Watt (16Ω) |
| Transmitter | |
|---|---|
| RF Output | 5/2W |
| Spurious | 70dB |
| Audio Response | +1 /-3dB from 6dB per octave pre-emphasis characteristic |
| Adjacent channel Power | 60dB |
| S/N Ratio | 40dB |
LED light-Lamp
Li-ion Battery Pack
2 unit charger
Rugged PTT Knob
Holster
Antennas
