Dreaming of becoming a leader in digital wireless communications
- Remote control
- Dual slot audio output
- Digital analog switch
-
External LE built-in
- Remote setup
- Firmware upgrade
- MP3 downloading -
Built-in SD Card
- Save and play MP3 files
| General | |
|---|---|
| XR-R1100 | 136 ~ 174 MHz |
| XR-R1400 | 400 ~ 470 MHz |
| Frequency stability | ±0.5ppm (-30 to +60℃) |
| Program channels | 500 channels (analog/digital use) |
| Zone | 32 (1 Zone = Max 32 Channels) |
| Channel spacing | 12.5KHz/25KHz |
| Digital vocoder | AMBE++ |
| Size | 44mm (H)×432mm (W)×320mm (D) |
| Weight | 7.7Kg |
| Power supply | DC-13.6V±15%, AC-90-264V |
| Power consumption (maximum) | Receive mode, audio output – 2A (Audio Max) |
| Power consumption (maximum) | Transmitting mode – 5A @ 10Watt, 11A@50Watt |
| Power consumption (maximum) | Standby mode – 800mA |
| Receiver | |
|---|---|
| Sensitivity | 0.25uV (BER 5%) |
| Selectivity | 60dB @12.5KHz / 70dB @ 25kHz |
| Spurious Rejection | 90dB |
| Mutual modulation | 60dB @12.5KHz / 60dB @ 25kHz |
| Blocking | 90dB |
| Audio output | 5Watt/4ohm load |
| Audio characteristics | +1, -3 dB from 6dB per octave de-emphasis Characteristic from 300 ~ 3000Hz |
| Input impedance | 50 ohms |
| Transmitter | |
|---|---|
| RF output | 5~25Watt |
| Adjacent channel power | 60dB @12.5KHz, 70dB @25KHz |
| Spurious | -36 dBm (< 1GHz) -30 dBm (> 1GHz) |
| Digital FSK error | <2% |
| FM modulation | 8K0F3E @12.5kHz / 16K0F3E @25kHz |
| Audio characteristics | +1, -3dB from 6dB per octave pre-emphasis Characteristic from 300 ~ 3000Hz |
| Output impedance | 50 ohms |
